Controls:
- Maximizing User Friendliness.
- Their main advantage is their intuitive and easy operation.
MOSAIC at a glance:
- High-performance controls from B&R
- Intuitive operation via 15″ colour touch screen with ergonomic tilt
- Swivel arm for a good view of the machine
- The wizard guides you through the setup and programming mode step by step
- Context-sensitive help function
- No page more than two clicks away
- Keyboard for entering notes and information
- The logical layout of 72 function keys with LEDs, arranged around the touchscreen
- Ethernet and 2 USB ports for connecting external devices
- USB stick for saving mould datasets, screenshots, and export report data
- Setpoint and actual values are shown as absolute values
- Plausibility check on input values
- Real-time charts for process analysis
- Process monitoring with graphic display of minimum, maximum, and average values
- Graphic display of 60 parameters for the last 100 cycles or, in a table format, for the last 700 cycles
- Machine status can be seen via Webserver
- Summary of last 3,000 alarms with the date and time stamps
- Display of last 3,000 setpoint changes (changelog)
- Internal memory for up to 150 mold data sets with assigned pictures
- 4+4 freely configurable inputs and outputs for connecting peripheral devices
- Data protection with five access levels for up to 30 machine operators
