Features:
- Individually driven Vertical / Inclined Calendar Unit
- Precisely manufactured rollers Hardened and Mirror finished surface for superior surface properties and excellent thickness control
- Motorized/Hydraulic gap adjustment for calendar roll for quick product changes
- Multilayer Feed Block & Flat sheet dies
- Melt pump for better pressure control for consistent thickness
- Automation through PLC with touch screen
- Specially Designed Winding System for Jumbo Rolls and 2/3 station Turret Winder
- Online Trim Recycling arrangement
- Lowest investment cost per ton of installed capacity
Applications:
- Cups & lids for Dairy Products, Yoghurt, Milk & Ice Creams
- Drinking cups/glasses
- Containers for fruit, vegetables & sweet packing
- Meal trays for microwave ovens
- Flower Pots, transportation trays & Agricultural Products
Technical Specifications:
| Material | Layers | Sheet | Output | |
|---|---|---|---|---|
| Width | Thickness | |||
| PP | 1 Layer | 400 to 1500 mm | 0.25 to 2.0mm | 200 to 2000 kg/hr |
| HIPS/PS | 2 Layer | |||
| PS/HIPS/PS | 3 Layer | |||
| PP/Tie/EVOH/Tie/PP | 5 Layers | |||
