Standard Features:
- 5 Point double Toggle clamping system of steel casting with steel link and steel bushes with tempered steel pins
- Hydraulic ejector through plate with multiple ejector cycles through nine strokes
- Multiple point automatic lubricating system
- Clamp closing and clamp opening profile with programmable and independent strokes and speeds
- Low pressure mould protection with high mould safety
- Freely programmable control of max. 2 core pulls and air for the control of max. 1 valve
- Mould opening and clamping in Four stages
- Mould setting gear arrangement by Hydro-motor
- Square tie bar distance with large mould height
- High tensile, hard-chrome platted tie bar
- Electrical interlocks in front and rear safety guards
- Ceramic heater
- High torque hydraulic motor for screw drive
- Automatic suck back system
- Four stage injection and four-stage holding time
- Cold start protection
- Gas-nitride screw barrel with standard L/D Ratio
- Injection movement is actuated by two hydraulic cylinders, for perfect alignment to the clamp unit
- Injection unit sliding on hard-chrome steel treated ground tie bars
- Stainless steel hopper with magnetic grill mounted on a swiveling system
- Injection speed, pressure, and holding time profile on 7 steps
- Proportional valve for pressure and flow control with electronic feedback
- Suction and return oil filter
- The component is easily accessible for maintenance purpose
- Resiliently mounted hydraulic pump
- Sealed oil tank with oil temperature
- 24 Volt DC solenoid valve
- Clamping and injection strokes are monitors by linear transducers
- M C B Control each heating zone
- Star Delta starter for pump motor 200 TO 650T
- Overload protection for pump motor
