We are also recognized for delivering highly functional and performance oriented range of Inline Round Drip Pipe Extruder Plants. These lines are precision designed for achieving the production of round drip irrigation pipes with inline round drippers. The extruder plants are designed to deliver pipes with wall thicknesses of 0.5~1.5mm.
Salient Features
- Maximum line speed of 45 mts / min for 600 mm dripper spacing.
- Complete line is controlled by PLC 10.3" touch panel.
- Dripper insertion is controlled by high precision servo motor.
- Dripper is automatically screened centrifugally before insertion.
- Vacuum tank is of stainless steel 6 mtr long.
- Drilling is by pneumatic rotary drill.
- Haul off is equipped with pneumatic cylinders to accommodate the dripper inside the pipe while passing through it.
- Haul off is controlled by two geared motors of 1.1 KW each for the perfect synchronization between two belts.
- Two station winder with separate torque motor is provided which is perfectly synchronized with the line speed of the machine.
Technical Specifications:
| Line Speed | 18 – 60 mts / min |
| Cylindrical drippers maximum | 300/min (Servo Controlled) |
| Transmission Speed Selection | 150 mts/min |
| Complete line controlled | 10-3" PLC touch panel |
| Emitter Spacing | 20 cms above set arbitrary ( variable pitch setting ) |
| Tractor Speed | 4 – 80 mts/min |
| Drilling Speed | 90/min |
| High Speed Drilling | 200/min |
| Line Length | 28m/34m |
| Vacuum Tank | 4 mtrs (Stainless steel) |
| Water Tank | 6/6*2 (Stainless steel) |
| Double Station Coiler | 500 mtrs – coil |
| Rated Power | 65 Kw |
