Features:
- 4 Station Gravimetric Blender with Extrusion Process Control
- Bimetallic Screw and Barrel ensure stable, Homogenious melt quality for longer period throughout operation
- PLC based machine with Inbuilt AC for control panel
- Insertion capacity 600 Drippers / Min
- 20 cm to 200 cm spacing setting for different configuration pipe
- Uniform spacing/ Group spacing/ Plain Pipe / Sample features included in PLC
- Perforation unit with perforation capacity 600 Drippers /Min
- Online visual Inspection system for Perforation and Dripper spacing check with or without Auto correction facility
- 2 station Auto Coiler with Synchronised Traversing, Auto pipe cut and auto bobbin change over
- 0.30 unit/kg power consumption
- Up to 160,000 – 240,000 – 330,000 meter Inline Pipe Production/Day
- Thickness Range for Flat Pipe: 0.20 mm to 0.8 mm
Technical Specifications:
| Model | Dripper Insertion Speed | Line Speed | Output kgs/hr |
|---|---|---|---|
| RRPP 45/33-45-150-STD Series | 300 | 100-120m/min | 150 |
| RRPP 75/33-90-300-Master Series | 600 | 160-180m/min | 300 |
| RRPP 75/33-110-400 Jet Master Series | 1000 | 200-250m/min | 40 |
