Specifications:
| MODEL | UNIT | SG-75 | SG-100 | SG-130 | SG-170 | SG-240 | SG-320 | SG-440 | SG-550 |
| Clamping Force | Ton | 75 | 100 | 130 | 170 | 240 | 320 | 440 | 550 |
| Clamping Stroke | mm | 280 | 320 | 360 | 430 | 525 | 650 | 750 | 850 |
| Tie-Bar Distance [HxV] | mm | 350×350 | 400×400 | 445×445 | 505×505 | 575×575 | 650×650 | 720×720 | 840×840 |
| Platen Size [HxV] | mm | 520×520 | 610×610 | 675×680 | 775×780 | 850×860 | 950×960 | 1100×1130 | 1220×1280 |
| Min.max mold Thickness | Mm | 125-350 | 150-400 | 150-470 | 200-550 | 200-700 | 200-750 | 350-800 | 350-900 |
| Ejector Stroke | mm | 100 | 100 | 120 | 140 | 160 | 200 | 205 | 225 |
| Injection Unit | — | 170 | 270 | 410 | 590 | 860 | 1180 | 2150 | 3220 |
| Screw Diameter | mm | 32 | 36 | 40 | 45 | 50 | 60 | 70 | 80 |
| Shot Wgt GPPS | gm | 130 | 165 | 240 | 330 | 445 | 735 | 1165 | 1710 |
| Injection Pressure | bar | 1358 | 1482 | 1568 | 1611 | 1751 | 1750 | 1615 | 1695 |
