| Model | PCF – 1000 | PCF – 1000/5 | PCR – 1000 | PSTG – 1000 |
| Length of Blades | 500 x 2 = 1000mm | 500 x 2 = 1000mm | 500 x 2 = 1000mm | 325mm-9,499x 2=4 |
| No. of Blades | 4 x 2 = 8 | 5 x 2 = 10 | 6 x 2 = 12 | 9 + 4 = 13 |
| Throat Size | 1000 x 800 mm | 1000 x 800 mm | 1000 x 800 mm | 1000 x 800 mm |
| Grinding Capacity | 800 Kgs/Hr | 1000 Kgs/Hr | 1000 Kgs/Hr | 1000 Kgs/Hr |
| Power Required | 60HP (45 KW) | 60HP (45 KW) | 60HP (45 KW) | 75HP (56.25KW) |
| Suitable for grinding | Barrels upto 200 Ltr. Dash Board, Bumpers of Cars. | 350mm Pipes & Pet Bottles | PVC tiles, films,sheets | Heavy duty pipes Lumps, Solid Wall Thick Articles |
